QNN1 Type Twin DC Neutral Q-Series Line Relay

The QNN1 Relay is a DC neutral, tractive armature, line relay designed for railway signaling and automation applications. It comprises two electrically independent relays mounted on a single base, making it functionally equivalent to two QN1 relays. This relay is engineered to operate at 12V, 24V, and 50V DC, offering high reliability in railway environments. It is widely used in railway interlocking, track circuit monitoring, and fail-safe operations. The QNN1 relay adheres to BR 930 Series standards, ensuring robust performance. Its compact structure and 8-pair contact limitation make it suitable for diverse railway applications.

Key Features:

● High Reliability: Designed for railway signaling applications.

● Dual Relay System: Functions as two QN1 relays in a single unit.

● Multiple Contact Arrangements: Available in 6F2B, 4F4B, and 2F2B configurations.

● Voltage Compatibility: Operates at 12V, 24V, and 50V DC.

● Compact & Durable: Built to withstand railway operational conditions.

● Plugboard Compatibility: Works with various railway signaling systems.

● BR 930 Series Compliance: Ensures standardized performance and safety.

It's Uses:

● Railway Signaling: Used in track circuit monitoring and interlocking systems.

● Safety Applications: Ensures fail-safe operation in railway networks.

● Automation Control: Supports train movement control systems.

● Relay Logic Operations: Works in railway signaling logic circuits.

● Replacement for QH1 Relays: Can replace QH1 relays in certain configurations.
